5/16" 1sn SAE100 at En853 High Pressure Hose
Consolidflex Industry Co., Ltd.- Material：Natural Rubber
- Capability：Heat-resistant Rubber Hose
- Color：Black
- Transport Package：Transparent Film
- Trademark：Consolidflex
- Origin：Hebei
Base Info
- Model NO.：1SN 5,16"
- HS Code：40093100
- Production Capacity：1000000meter,Year
Description
Burst PressureMinimum Bend Radius Weight inch mm mm MPa psi MPa psi mm kg/m 5 3/16" 4.8 11.8 25 3630 100 14280 89 0.19 6 1/4" 6.4 13.4 22.5 3270 90 12840 102 0.21 8 5/16" 7.9 15 21.5 3120 85 12280 114 0.24 10 3/8" 9.5 17.4 18 2615 72 10280 127 0.33 13 1/2" 12.7 20.6 16 2320 64 9180 178 0.41 16 5/8" 15.9 23.7 13 1890 52 7420 203 0.45 19 3/4" 19 27.7 10.5 1530 42 6000 241 0.58 25 1" 25.4 35.6 8.8 1280 35 5020 305 0.88 32 1 1/4" 31.8 43.5 6.3 920 25 3600 419 1.23 38 1 1 /2" 38.1 50.6 5 730 20 2860 508 1.51 51 2" 50.8 64 4 580 16 2280 635 1.97
Tube:Oil resistant, synthetic rubber;
Reinforcement:One braid of high tensile steel wire;
Cover:Oil and weather resistant synthetic rubber;
Temperature:-40° F / +212° F, Intermittent use up to 250° F;
Application:Petroleum based hydraulic fluid,water, diesel fuels, lubricating oils, glycol, mineral oils, and more;
Tube:Oil resistant, synthetic rubber;
Reinforcement:One braid of high tensile steel wire;
Cover:Oil and weather resistant synthetic rubber;
Temperature:-40° F / +212° F, Intermittent use up to 250° F;
Application:Petroleum based hydraulic fluid,water, diesel fuels, lubricating oils, glycol, mineral oils, and more;
