• Model NO.：carbon black
• Mf：Sio2.Nh2o
• Einecs No：238-878-4
• Keywords：Carbon Black
• Transport Package：25kg,Bag
• Specification：carbon black
• Trademark：ZZSAN
• Origin：China
• HS Code：2803000000
• Production Capacity：150000

ITEM

N220

N330

N550

N660

Iodine Absorption Number, g/kg

121 +/-5

82 +/-5

43 +/-4

36 +/-4

DBP Absorption Number, 10-5m3/Kg

114 +/-5

102 +/-5

121 +/-5

90 +/-5

DBP Absorption Number of Compressed Sample, 10-5m3/Kg

93~107

81~95

81~95

68~82

CTAB Surface Area, 103m2/Kg

106~116

79~87

38~46

31~39

Nitrogen Surface Area, 103m2/Kg

114~124

78~88

38~46

30~40

Tint Strength

110~120

98~108

-

-

Heating Loss, %≤

3.0

2.5

2.5

1.5

Ash, %≤

0.5

0.5

0.5

0.5

Tensile Strength Map, MPa≥

-0.8

-1.5

-3.5

-3.5

Extension, %≥

+10

-10

-10

+10

Map Modulus at 300%, MPa

-2.5 +/-1.3

-1.7 +/-1.3

-1.7 +/-1.3

-3.5 +/-1.3

Carbon black is a basic material with a long history, and it has been used as a coloring agent since the days before Christ. Since carbon black has nano-particles with various functions such as ultra-violet absorption and conductivity, it is still being applied to new fields such as electronic equipment and devices. Some applications of carbon black, which is a conventional yet new material, are shown below.

1 ) Coloring Agent for Ink and Paints

Carbon black has higher tinting strength compared to iron black or organic pigments, and is widely used for newspaper inks, printing inks, India inks, and paints. Carbon black is also used as black pigment for inkjet ink or toners.

2 ) Resin and Film Coloring Agents

Carbon black has high tinting strength and is thermally stable, and therefore it is suitable for coloring resins and films that are heat-formed. Carbon black is also excellent for absorbing ultraviolet light, providing both a superb resistance against ultraviolet rays and a coloring effect when just a small amount is mixed with resins. Carbon black is widely used for general coloring for resins and films. Resins with carbon black are used in automobile bumpers, wire coverings and steel pipe linings which require weather resistance in particular.

3 ) Electric Conductive Agent

Carbon black particles have the graphite-type crystalline structure, providing an excellent electric conductivity. Therefore, carbon black is widely used as conductive filler, being mixed in plastics, elastomer, paints, adhesives, films, and pastes.
Fuel caps and fuel-introducing pipes of automobiles, for example, are required of electric conductivity for preventing static. Therefore, carbon black is used as an excellent antistatic agent.

4 ) Electronic Equipment Related Material

Carbon black also provides stable resistance, and therefore is used as electronic equipment related material in various display components, magnetic recording materials, and OA rolls.
Furthermore, Mitsubishi Chemical has been developing carbon black with various combined functions for special applications.

Packaging & Shipping

20 or 25kg/pp bag,or per customer's request.

in 7-15 days after receiving the order.

Transit could be DHL,UPS,TNT,EMS,Fedex,and so on.

For mass orders, it will be delivered by air or sea.

Depending on your location, please allow 1-5 business days for your order to arrive.

For small order, please expect 3-7 days by UPS DHL EMS.

For mass order, please allow 5-8 days by Air, 15-30 days by Sea.
