Abrasive Resistant Slurry/Concrete Transfer Hose with Steel Wire Reinforcement
VELON INDUSTRIAL INC.- Material：EPDM
- Capability：Mining Hose
- Color：Color
- W.P.：232 Psi , 16 Bar
- B.P.：928 Psi , 48 Bar
- Length：20, 60 M,Roll
Base Info
- Temperature：- 40˚c to + 120˚c
- Tube：EPDM
- Reinforcement：High Tensile Textile Cord, Steel Helix
- Cover：EPDM
- Application：Abrasive Material Handing, etc.
- Certification：Msha
- Transport Package：Customized Packaging
- Specification：1"- 10"
- Trademark：Velon, OEM
- Origin：China, Malaysia, etc.
- HS Code：40093100
- Production Capacity：800, 000 M,Month
Description
B.P.N.P. MBR Weight Length (inch) (mm) (mm) (bar) (psi) (bar) (psi) (bar) (mm) (kg/m) (m) 1" 25 35 16 232 48 928 0.9 100 0.67 60 1-1/4" 32 42 16 232 48 928 0.9 128 0.84 60 1-1/2" 38 49 16 232 48 928 0.9 152 1.06 60 2" 51 62 16 232 48 928 0.9 204 1.49 60 2-1/2" 64 77 16 232 48 928 0.9 252 2.23 60 3" 76 90 16 232 48 928 0.9 304 2.71 60 4" 102 117 16 232 48 928 0.9 408 3.79 60 5" 127 145 16 232 48 928 0.9 508 6.04 60 6" 152 172 16 232 48 928 0.9 760 8.48 60 8" 203 229 16 232 48 928 0.9 1015 14.01 20 10" 254 284 16 232 48 928 0.9 1270 19.53 20
Tube: EPDM black, smooth, abrasion resistant, antistatic (R ≤ 1MΩ)
Reinforcement: High tensile textile cord, steel helix
Cover: EPDM black, smooth with cloth impression, abrasion, weather and ozone resistant
Temperature range: - 40˚C to + 120˚C
Applications: EPDM suction and discharge hose for domestic water, industrial water, effluents, slurry and liquid manure, abrasion<180mm3
Tube: EPDM black, smooth, abrasion resistant, antistatic (R ≤ 1MΩ)
Reinforcement: High tensile textile cord, steel helix
Cover: EPDM black, smooth with cloth impression, abrasion, weather and ozone resistant
Temperature range: - 40˚C to + 120˚C
Applications: EPDM suction and discharge hose for domestic water, industrial water, effluents, slurry and liquid manure, abrasion<180mm3
