Rubber Ceramic Moulded Wear Plate as Ceramic Wear Panels
Pingxiang Chemshun Ceramics Co., Ltd.- Material：Natural Rubber
- Usage：Industrial
- Feature：Wear-resistant, Impact-resistant, Heat-resistant, Corrosion-resistant, Cold-resistant
- Raw Materials：Natural Rubber, Pad
- Medium：Alumina Ceramic Backed Rubber Sheet
- Performance：Wear and Impact Resistance
Base Info
- Model NO.：Chemshun ceramic
- Color：Black Rubber Sheet
- Size：300*300mm 500*500mm
- Item：Rubber Ceramic Composite
- Alumina Content：92% 95%
- Polular Application：Cement, Steel, Mining, Power Generation, Port
- Firing Temperature：1680
- OEM：Design According Customer′s Drawings
- Structure：Ceramics+Rubber+Steel
- Vulcanized Ceramics Shape：Ceramic Plate, Hexagonal Ceramics , Cylinder etc
- Transport Package：Cartons Fixed on Pallet or Wooden Case
- Specification：100*100MM, 200*200Mm, 300*300MM, 500*500 MM
- Trademark：CHEMSHUN
- Origin：Pingxiang, Jiangxi, China
- HS Code：69091200
- Production Capacity：350 Ton,Month
Description
Discharge Chute, Transfer Chute, Reflectors And Impact Plate,
Conveyor Skirt Liners, Stacker And Reclaimers, Hoppers And Silos,
Bunker & Bin, Belt Stock House, Coal Feeder, Coal hopper,
5: Chemshun ceramic rubber plate property:
| Property | Value |
| Normal Size | 500*500mm , 300*300mm,250*250mm |
| Ceramic Thickness | 15~50mm |
| Rubber Thickness | 3mm~10mm |
| Type of Rubber | Vulcanized natural rubber compound with carbon black filler (approx 40%) |
| Rubber Shore A hardness | 45 (+/-5) |
| Rubber Tensile Strength | 2710 psi |
| Rubber Elongation | 600% |
| Rubber-ceramic bond | Surface chemical pre-treatment of ceramic prior to hot pressure vulcanized |
| Ceramic tile (Thk) | 2mm~50mm (mosaic tiles, plain tile etc.) |
| Vulcanized ceramics | Square mosaic tile, rectange tile , plain tile , hex tile , cylinder |
| Alumina Content | Al2O3 92%, 95% |
