Super Flexible Low Bending Radius Fuel/Oil Delivery Rubber Hose
VELON INDUSTRIAL INC.- Material：Nitrile Rubber
- Capability：Rubber Oil Hose
- Color：Color
- W.P.：250 Psi , 17 Bar
- B.P.：1000 Psi , 68 Bar
- Length：60 M,Roll
Base Info
- Model NO.：SDSO
- Temperature：- 40˚c to + 90˚c
- Tube：Nitrile Rubber
- Reinforcement：High Tension Textile Cord or Fabric, Copper Wire
- Cover：Nitrile Rubber
- Application：Fuel, Oil, Sea Water, Fresh Water
- Transport Package：Customized Packaging
- Specification：3,4" - 4"
- Trademark：Velon, OEM
- Origin：China, Malaysia, etc.
- HS Code：40093100
- Production Capacity：500, 000 M,Month
Description
B.P.N.P. MBR Weight Length (inch) (mm) (mm) (bar) (psi) (bar) (psi) (bar) (mm) (kg/m) (m) 3/4" 19 31 17 250 68 1000 0.9 40 0.65 60 1" 25 37 17 250 68 1000 0.9 50 0.81 60 1-1/2" 38 51 17 250 68 1000 0.9 80 1.08 60 2" 51 64 17 250 68 1000 0.9 100 1.43 60 2-1/2" 64 78 17 250 68 1000 0.9 130 2.10 60 3" 76 91 17 250 68 1000 0.9 150 2.51 60 4" 102 120 17 250 68 1000 0.9 200 3.61 60
Technical Description
Tube: Black nitrile synthetic rubber with oil resistance grade A
Reinforcement: High tension textile fabric / cord, helix steel wire
Cover: Black synthetic rubber, aging resistance, ozone resistance
Temperature range : - 40˚C to + 90˚C
Applications: Supflex hose is suitable for application in small space and corner, hose with properties of light weight and excellent oil resistance.
Technical Description
Tube: Black nitrile synthetic rubber with oil resistance grade A
Reinforcement: High tension textile fabric / cord, helix steel wire
Cover: Black synthetic rubber, aging resistance, ozone resistance
Temperature range : - 40˚C to + 90˚C
Applications: Supflex hose is suitable for application in small space and corner, hose with properties of light weight and excellent oil resistance.
