Wire Reinforced SAE J1527 Marine Fuel Hose
Hangzhou Haikuo Rubber and Plastic Products Co., Ltd.- Material：Nitrile Rubber
- Capability：Rubber Oil Hose
- Color：Black, Grey, Blue, Yellow, Red, etc
- I.D：3,16"-11,2"
- W.P：Max.20bar
- B.P：Max.60bar
Base Info
- Model NO.：Wire Reinforced SAE J1527 Marine Fuel Hose
- Length：100m, 50meters
- Temperature：-30~80c Degree
- Brand：Print and Embossed
- Delivery Detail：by Order
- Surface：Smooth,Textile Surface
- Transport Package：Plastic Film
- Specification：SAE J1527
- Trademark：High-Qua or OEM
- Origin：Zhejiang, China (Mainland)
- Production Capacity：100000m,Month
Description
I.D.O.D. W.P. REIFORCE LAYER WEIGHT UNIT LENGTH in. mm in. mm psi. mpa. kg/m m/roll 3/16 4.8 0.45 11.5 300 2.07 1 0.15 100 1/4 6.4 0.63 16 300 2.07 1 0.18 100 5/16 7.9 0.59 15.0 300 2.07 1 0.22 100 3/8 9.5 0.75 19.1 300 2.07 1 0.27 100 1/2 12.7 0.91 23.1 300 2.07 1 0.40 100 5/8 15.9 0.96 24.5 300 2.07 1 0.50 100 3/4 19.1 1.14 29.0 300 2.07 1 0.75 100 3/4 19.1 1.18 30.0 300 2.07 2 0.80 100 1 25.4 1.42 36.1 300 2.07 1 0.95 100 1 25.4 1.42 36.1 300 2.07 2 0.95 100 1 1/4 31.8 1.75 44.5 300 2.07 2 0.70 50 1 1/2 38.1 2" 54.0 300 2.07 2 0.85 50
Material: NBR, which meets RMA-B grade (medium/ high level oil resistance)
Color available: Black red or other color
Structure: 1)Interior and exterior rubber lining use oil-endurable compound rubber formula.
2)Meddle lining is high strengthen weaving fiber.
Working Temperature: -30oC~80oC
Product Application
It is applied to circulating diesel, biodiesel, hydraulic oil, machinery oil and lubricating oil etc, or the oil products with the contents of aromatic substances not more than 30%.
Material: NBR, which meets RMA-B grade (medium/ high level oil resistance)
Color available: Black red or other color
Structure: 1)Interior and exterior rubber lining use oil-endurable compound rubber formula.
2)Meddle lining is high strengthen weaving fiber.
Working Temperature: -30oC~80oC
Product Application
It is applied to circulating diesel, biodiesel, hydraulic oil, machinery oil and lubricating oil etc, or the oil products with the contents of aromatic substances not more than 30%.
Packaging&Shipping
Packaging Details: By transparent plastic film and woven belt or your request.
Delivery Time: We are responsible for shpping goods to delivery port on time.
