• Model NO.：100~600N,mm
• Scope：Belt Conveyor, Screw Conveyor and So on
• The Strength Specifications：100n,mm 125n,mm 150n,mm 200n,mm 250n,mm 300n,mm 40
• Belt Width：400-2200mm
• Sample：Available
• Discount：More Discount with a Larger Quantity
• Transport Package：PVC Water Proof Cloth
• Specification：DIN; AS; RMA; SABS; BS; JISK
• Trademark：Huayue
• Origin：Baoding City Hebei Province China
• HS Code：4010120000
• Production Capacity：5000 Meter Per Day

GradeTensile Strength/Mpa ≥Breaking Elongation/% ≥Abrasion Loss/mm3 ≤H24450120D18400100L15350200

Note:

Grade H-used for transporting sharp, abrasive materials which can damage belts badly.

Grade D-used for transporting highly abrasive materials.

Grade L-used for transporting medium-abrasion materials.

After-aging properties of rubber cover(70ºC, 7days):

Tensile strength and breaking elongation are both not lower than 75% of before-aging values.



Full-thickness Tensile Properties

a. Longitudinal tensile strength, not less than the below table. (N/mm)

Nominal belt type160200250315400500630800100012501600200025003150

b. Full thickness, longitudinal elongation at reference force, not more than 4%.

c. Ply adhesion:

ItemPly to plyRubber cover to plyRubber cover thickness ≤1.5mmRubber cover thickness >1.5mmAll samples average value/ (N/mm) ≥4.53.23.5All samples min peak value/ (N/mm) ≥3.92.42.9Note: All samples max peak value is not more than 20N/mm.

d. Straightness not more than 25mm

Over 30 years reputation, professional manufacture for various conveyor belt. Welcome enquiry us!
Polyester conveyor belt, (EP)
Nylon conveyor belt, (NN)
Cotton conveyor belt, (CC)
Chevron conveyor belt, (C5 C10 and C15)
Oil Resistance conveyor belt, (OR and MOR)
Hot Resistance conveyor belt, (HR)
Fire Resistance conveyor belt, (FR/PVC/PVG)
Heat Resistance conveyor belt, (OHR/ OFR)
Cold Resistance conveyor belts, (CR)
Endless belts
Conveyor roller, idler
Conveyor Pulley, frame, bracket etc.
