• Model NO.：cc56, cc60
• Model Number：Cc56, Cc60
• Certificate：ISO9001:2008, Bureau Veritas Certification
• Standards：GB,T7984-2001, DIN22102, Bs490, As1332, Rma, Jisk6
• Scope：Belt Conveyor, Screw Conveyor and So on
• Condition：New
• The Strength Specification：100n,Mm 125n,Mm 150n,Mm 200n,Mm 250n,Mm 300n,Mm 40
• Belt Width：400-2200mm
• Transport Package：PVC Water Proof Cloth or Customized
• Specification：DIN; AS; RMA; SABS; BS; JISK
• Trademark：Huayue
• Origin：Baoding City Hebei Province China
• HS Code：4010120000
• Production Capacity：5000meters,Day

Basic Info.

Model NO. cc56, cc60 Model Number Cc56, Cc60 Certificate ISO9001:2008, Bureau Veritas Certification Standards GB/T7984-2001, DIN22102, Bs490, As1332, Rma, Jisk6 Scope Belt Conveyor, Screw Conveyor and So on Condition New The Strength Specification 100n/Mm 125n/Mm 150n/Mm 200n/Mm 250n/Mm 300n/Mm 40 Belt Width 400-2200mm Transport Package PVC Water Proof Cloth or Customized Specification DIN; AS; RMA; SABS; BS; JISK Trademark Huayue Origin Baoding City Hebei Province China HS Code 4010120000 Production Capacity 5000meters/Day

Product Description

High quality cotton conveyor belts


Standards:
GB/T7984-2001, DIN22102, BS490, AS1332, RMA, JISK6322, SABS1173 etc.
Physical and mechanical properties of covering layer
Rank of overburden performance H D L

Tensile strength(Mpa)≥ 24.0 18.0 15.0

Elongation at break(%)≥ 450 400 350

Abrasion value(mm3)≤ 120 100 200

Tensile property of total thickness:
1. Tha longitudinal tensile strength of the conveyor belt is not lower than the following nominal value: 160 200 250 315 400 500 600 630 800N/mm
2. The total thickness elongation rate of the belt should not less than 10%, the reference force elongation rate of total thickness of the belt should no more than 4%.
3. Straightness: No more than 25mm.

Welcome to inquiry us.
