Rubber Acetylene Hose En559 Welding Hose
Qingdao Hyrubbers Co., Ltd.- Material：Natural Rubber
- Capability：Rubber Oil Hose
- Color：Color
- 1/4"-1"：Red Color, Black Color, Yellow Color
- Transport Package：by plastic films
- Specification：EN559, GOST 9356-76
Base Info
- Model NO.：EN857
- Trademark：hyrubbers
- Origin：China
- HS Code：40093100
- Production Capacity：70000m,day
Description
Basic Info.
Model NO. EN857 Trademark hyrubbers Origin China HS Code 40093100 Production Capacity 70000m/dayProduct Description
Description:
- 1. Material: Inner tube is made of SBR or NR; or SBR&NR blend; outer cover is made of SBR or NR; or SBR&NR blend
- 2. Structure: 1.Common type:Interior lining +Strengthen lining +Exterior lining. Strength type (three lining and two weaving fiber):Add middle rubber lining and a weaving fiber base on the common type.
- 3. Color: black, red, blue, green, yellow, white, grey
- Standard length: 50m, 100m
- 4.Temperature range: -30ºC to +80 ºC
| ID (mm) | Wall (mm) | WP (bar) | BP (bar) | Radius (mm) | Weight (kg/m) |
| 5 | 3,2 | 20 | 60 | 30 | 0.15 |
| 5 | 3,2 | 20 | 60 | 30 | 0.15 |
| 6 | 3,5 | 20 | 60 | 35 | 0.17 |
| 6 | 3,5 | 20 | 60 | 35 | 0.17 |
| 8 | 3,5 | 20 | 60 | 50 | 0.25 |
| 8 | 3,5 | 20 | 60 | 50 | 0.25 |
| 9 | 3,5 | 20 | 60 | 50 | 0.27 |
| 9 | 3,5 | 20 | 60 | 50 | 0.27 |
| 10 | 3,5 | 20 | 60 | 60 | 0.29 |
| 10 | 3,5 | 20 | 60 | 60 | 0.29 |
| 13 | 4,5 | 20 | 60 | 60 | 0.39 |
| 13 | 4,5 | 20 | 60 | 60 | 0.39 |
| 16 | 4,5 | 20 | 60 | 70 | 0.45 |
| 16 | 4,5 | 20 | 60 | 70 | 0.45 |
| 19 | 5,5 | 20 | 45 | 80 | 0.58 |
| 19 | 5,5 | 20 | 45 | 80 | 0.58 |
