Factory Produce Thermoplastic Hydraulic Hose R7 R8
Qingdao Hyrubbers Co., Ltd.- Material：Nitrile Rubber
- Capability：Heat-resistant Rubber Hose
- Color：Black
- 1/4"~2"：Thermoplastic Hydraulic Hose with R7 R8
- Transport Package：BY PLASTIC FILMS OR PLASTIC BAGES
- Trademark：hyrubbers
Base Info
- Model NO.：SAE100 R7
- Origin：China
- HS Code：40092100
- Production Capacity：5000M,DAY
Description
DNHose I. D Hose O. D Working Pressure Burst Pressure Minimum Bend Radius Weight Length inch mm mm MPa psi MPa psi mm kg/m metres 3 1/8 3.3 8.5 17.2 2500 68.9 10000 13 0.037 20~100 5 3/16 4.8 10.8 20.7 3000 82.7 12000 20 0.068 20~100 6 1/4 6.4 13.0 20.7 3000 82.7 12000 33 0.085 20~100 8 5/16 7.9 15.1 17.2 2500 68.9 10000 46 0.103 20~100 10 3/8 9.5 17.0 15.5 2250 62.1 9000 51 0.141 20~100 13 1/2 12.7 20.7 13.8 2000 55.2 8000 76 0.210 20~100 19 3/4 19.0 27.1 8.6 1250 34.5 5000 127 0.287 20~100 25 1 25.4 34 6.9 1000 27.6 4000 203 0.542 20~100
