American and Germany Standard Hydraulic Hose for Oil
Hangzhou Haikuo Rubber and Plastic Products Co., Ltd.- Material：Nitrile Rubber
- Capability：Rubber Oil Hose
- Color：Black, Red, Blue, Yellow, Green, etc
- Size：1,4" ~ 2"
- W.P：100 ~500bar
- B.P：400 ~ 2000bar
Base Info
- Model NO.：Hydraulic Hose For Oil Manufacturer
- Type：R1. R2. R3. R4. R5. R6. R12. R17 etc
- Surface：Cloth,Smooth Surface Hydraulic Hose
- Brand：Print and Embossed
- Certification：ISO9001
- Delivery Time：Within 15 Days Usually
- Reinforcement：One or Two Layer Steel Wire Braid
- Quality：Top Grade Quality
- Transport Package：Well Be Packed in Plastic Film ,Woven Bag.
- Specification：ROHS, CE, SGS certificate
- Trademark：OEM or HIGH-QUA
- Origin：Zhejiang
- HS Code：4009410000
- Production Capacity：500000m Per Week
Description
Part No.Hose Size ID Hose OD Max. Working Pressure Min. Bend Radius Min. Burst Pressure Weight in DIN in mm psi mpa in mm psi mpa kg/m 2SN-03 3/16 4.8 0.48 13.4 6000 41.4 3.5 89 24000 165.5 0.31 2SN-04 1/4 6.4 0.59 15.1 5800 40 4 100 23200 160 0.33 2SN-05 5/16 7.9 0.65 16.6 5000 35 4.5 115 20300 140 0.39 2SN-06 3/8 9.5 0.75 19.1 4800 33.1 5 125 19200 132.4 0.50 2SN-08 1/2 12.7 0.88 22.2 4000 27.6 7 180 16000 110.3 0.59 2SN-10 5/8 15.9 1 25.4 3630 25 8 200 14520 100.1 0.71 2SN-12 3/4 19 1.16 29.4 3120 21.5 9.5 240 12480 86 0.86 2SN-16 1 25.4 1.5 38.1 2400 16.5 12 300 9600 66.2 1.28 2SN-20 1 1/4 31.8 1.88 48.3 1820 12.5 16.5 420 7280 50.2 2.02 2SN-24 1 1/2 38.1 2.13 54.6 1310 9 20 500 5240 36.1 2.20 2SN-32 2 50.8 2.63 67.3 1160 8 25 630 4640 32 2.85
