Multi-Color Plastic Helix PVC Suction Hose
Qingdao Kingdaflex Industrial Co., Ltd.- Material：PVC
- Capability：PVC Suction Hose
- Color：Color
- W.P：10 Bar
- B.P：30 Bar
- I.D：20-203mm
Base Info
- Model NO.：PVC suction hose
- Length：50m
- Weight：140-2800 G,M
- Certification：ISO,SGS
- Shape：Round
- Transport Package：Seaworthy Package
- Specification：3,4"-8′
- Trademark：OEM
- Origin：China
- HS Code：39173900
- Production Capacity：1000000 Meters Per Month
Description
Basic Info.
Model NO. PVC suction hose Length 50m Weight 140-2800 G/M Certification ISO,SGS Shape Round Transport Package Seaworthy Package Specification 3/4"-8′ Trademark OEM Origin China HS Code 39173900 Production Capacity 1000000 Meters Per MonthProduct Description
Multi-Color Plastic steel tube PVC Suction HoseProduction Informations:
1. Rigid PVC spiral reinforced between walls.
2. Inside absolutely smooth, outside spiral.
3. Temperature: -15° C~70° C, shortly in 80° C.
4. Lengths: Max 30meters
5. Inside diameter: 19-250mm.
6. Colors: As required.
7. UV protected is available.
8. Suitable for suction water, some solids and oils in industry.
Specifications:
| INCH | ID(mm) | OD(mm) | W.P (Bar) | B.P (Bar) | Length(M) |
| 3/4" | 19 | 25 | 9 | 31 | 30 |
| 1" | 25 | 32 | 9 | 31 | 30 |
| 1-1/4" | 32 | 38 | 9 | 31 | 30 |
| 1-1/2" | 38 | 46 | 9 | 31 | 30 |
| 2" | 50 | 60 | 8 | 28 | 30 |
| 2-1/2" | 64 | 73 | 7 | 24 | 30 |
| 3" | 76 | 86 | 6 | 21 | 30 |
| 4" | 102 | 113 | 6 | 21 | 30 |
| 5" | 127 | 139 | 5 | 17 | 30 |
| 6" | 152 | 166 | 5 | 17 | 30 |
| 8" | 203 | 219 | 4 | 14 | 8 |
