Red Fire Suppression Hose /Hydraulic Rubber Hose R1at
Hangzhou Haikuo Rubber and Plastic Products Co., Ltd.- Material：SBR,NBR,EPDM or by Request
- Capability：Water Rubber Hose
- Color：Black,Grey,Blue,Yellow,Red,etc
- I.D：3,16"-2"
- W.P：250 ~ 400bar
- B.P：1000-1600bar
Base Info
- Model NO.：Fire Suppression Hose ,Hydraulic Rubber Hose R1AT
- Length：100,50.40.20meters
- Cover：Msha, Flame Resistant
- Constructure：NBR, Cr, Steel Wire Braided
- Surface：Smooth or Cloth
- Brand：Print and Embossed
- Delivery Detail：According to The Order
- Shipment：by Sea or by Express
- Transport Package：Plastic Film, Woven Bags
- Specification：ISO, SGS
- Trademark：High-Qua or OEM
- Origin：Zhejiang, China (Mainland)
- Production Capacity：100000m,Month
Description
DIN EN 853 1SNDN Hose I.D Wire O.D Hose O.D W.P B.P MBR Weight Length inch mm mm mm Bar Bar mm kg/m metres 5 3/16 4.8 9.5 11.8 250 1000 89 0.19 50/100 6 1/4 6.4 11.1 13.4 225 900 102 0.21 50/100 8 5/16 7.9 12.7 15 215 850 114 0.24 50/100 10 3/8 9.5 15.1 17.4 180 720 127 0.33 50/100 13 1/2 12.7 18.3 20.6 160 640 178 0.41 50/100 16 5/8 15.9 21.4 23.7 130 520 203 0.45 50/100 19 3/4 19.0 25.4 27.7 105 420 241 0.58 50 25 1 25.4 33.3 35.6 88 350 305 0.88 50 32 1 1/4 31.8 40.5 43.5 63 250 419 1.23 20 38 1 1/2 38.1 46.8 50.6 50 200 508 1.51 20 51 2 50.8 60.2 64 40 160 635 1.97 20
