Polyester/Ep Conveyor Belt for Cement
Baoding Huayue Rubber Belts Co., Ltd.- Type：Conveyor Belt
- Feature：Wear-resistant, Heat-resistant, Tear-resistant, Flame-resistant, Cold-resistant
- Certificate：ISO9001:2008, SGS, Bureau Veritas Certification
- Standards：GB,T7984-2001, DIN22102, Bs490, As1332, Rma, Jisk6
- Belt Width：400-2200 Mm
- Strength：100n,Mm 125n,Mm 150n,Mm 200n,Mm 250n,Mm 300n,Mm 40
Base Info
- Model NO.：EP
- Guarantee：1 Year (Wear Parts Excluded)
- Condition：High Abrasion Resistance
- Tensile：High Strength, and High Strength
- Material：Rubber and Polyester Fabric
- Scope：Belt Conveyors
- Capacity：40-1280 T,H
- Transport Package：Standard Export Packing
- Specification：SGS, ISO, BV
- Trademark：HUAYUE
- Origin：Hebei Baoding
- HS Code：4010120000
- Production Capacity：5000m Per Day
Description
StandardsCover Rubber Adhesion Tensile Strength Elongation at break Abrasion Cover to Ply Cover to Ply Ply to Ply DIN 22102 Mpa % mm3 N/mm
(<=1.5mm) N/mm
(>1.5mm) N/mm DIN 22102-Z 15 350 250 3.5 4.5 5 DIN 22102-W 18 400 90 3.5 4.5 5 DIN 22102-Y 20 400 150 3.5 4.5 5 DIN 22102-X 25 450 120 3.5 4.5 5 Cover Rubber Adhesion Tensile StrengTD Elongation at break Abrasion Cover to Ply Cover to Ply Ply to Ply AS 1332 Mpa % mm3 N/mm
(≤1.9mm) N/mm
(>1.9mm) N/mm AS 1332-N17 17 400 200 4 4.8 6 AS 1332-M24 24 450 125 4 4.8 6 Cover Rubber Adhesion Tensile StrengTD Elongation at break Abrasion Cover to Ply Cover to Ply Ply to Ply RMA Mpa % mm3 N/mm
(≤1.6mm) N/mm
(>1.6mm) N/mm RMA-I 17 400 3 4.4 4 RMA-II 14 400 3 4.4 4 Cover Rubber Adhesion Tensile StrengTD Elongation at break Abrasion Cover to Ply Cover to Ply Ply to Ply SANS 1173 Mpa % mm3 N/mm N/mm A 18 400 70 5 7 C 20 400 150 5 7 M 25 450 120 5 7 N 17 400 150 5 7
(<=1.5mm)
(>1.5mm)
(≤1.9mm)
(>1.9mm)
(≤1.6mm)
(>1.6mm)
