• Model NO.：3A5007
• Color：Black, Grey, Red
• Quality：Industial Grade, FDA Grade
• Surface：Smooth
• Tensile Strength：7-12MPa
• Hardness：70+,-5shore a
• Elongation：200%
• Density：1.9-2.1g,cm3
• Thickness：1-20mm
• Width：1-2m
• Length：1-20m
• Transport Package：Packing in Rolls and Pallets
• Specification：CE
• Trademark：3A Rubber
• Origin：China
• HS Code：40082100
• Production Capacity：100000kgs,Month

Basic Info.

Model NO. 3A5007 Color Black, Grey, Red Quality Industial Grade, FDA Grade Surface Smooth Tensile Strength 7-12MPa Hardness 70+/-5shore a Elongation 200% Density 1.9-2.1g/cm3 Thickness 1-20mm Width 1-2m Length 1-20m Transport Package Packing in Rolls and Pallets Specification CE Trademark 3A Rubber Origin China HS Code 40082100 Production Capacity 100000kgs/Month

Product Description

FKM Sheet, FKM Rubber Sheet, Fluorubber Rubber Sheet, Fluorubber Sheet for Industrial Seal


Description: the fluorubber sheet, FKM sheet are made by drum-type vulcanizing press(ROTOCURE) or plain vulcanizing press with high quality fluorubber, 1-6mm thickness is made by drum-type vulcanizing press(ROTOCURE) with shiny surface, 7-20mm thickness is made by vulcanizing press for get higher thick thickness. With many high characters such as high heat aging resistance, high temperature resistant, ozone resistant, oil resistant, vacuum resistant, acid & alkali resistant, chemic cautery resistant. It could work in air, oil, acid or alkali and all kinds of other chemic solution which contains 100% cautery material at the temperature of -40°C - +320°C. Appearance of product this type feels gleaming and flattening. Allowable variation of thickness is tiny and all physical indexes are excellent. With outstanding performances of high temperature resistant, oil-proof, strong acid and alkali proof the product could withstand hard environment's test. Multi hardness fluorin rubber plate with 2m ultimate thickness and 0.5mm ultimate thinness could meet the requirement of all industries. Apply to punch all kinds of seals, gaskets at military, spaceflight, chemical industry and other high-tech request. Allowed buyers offer particular technical demand such as insulation, textile insertion, metal mesh insertion and mat surface, we could make it according to contract signified.



Specifications:

material: virgin fluorubber

quality: industrial grade, FDA grade (postcure)

color: black, brown, red, green, yellow, white etc.

surface: smooth/smooth, smooth/impression fabric, double impression fabric

reinforce: insert 1-3 PLY fiberglass fabric, aramid fabric or wire mesh SS201, SS304, SS316

tensile strength: 7-12Mpa

hardness: 60, 70+/-5Shore A

elongation: 200%

density: 1.9-2.1g/cm³

working temperature: -40°C - +320°C

thickness: 0.5-20.0mm

width: 0.1-2.0m

length: 0.1-20m

***when you enquiry, pls confirm the size and quantity***

Also supply FKM cord, FKM hose, FKM gasket, FKM ring etc.
