Large Diameter Agricultural Felxible Water Hose
PAPAGENO GROUP CO., LTD.- Material：PVC
- Capability：Water Rubber Hose
- Color：Customized
- Working Pressure：2-10bar
- Length：Customized
- Thickness：1-3mm
Base Info
- Model NO.：PVC Layflat Hose
- Working Temperature：-5-65 Degree Centigrade
- Transport Package：Woven Bags
- Specification：ROHS
- Trademark：Papageno
- Origin：Tianjin
- HS Code：39173900
- Production Capacity：10000m,Day
Description
LIGHT DUTY PVC LAY FLAT HOSEPARTNO. INCH I.D
(MM) THICKNESS
(MM) W.P.@23ºC
(BAR) LENGTH
(M/ROLL) WEIGHT
(KG/ROLL) GNLF2504 1" 25 1.3 4 100 15 GNLF3204 1-1/4" 32 1.2 4 100 17 GNLF3804 1-1/2" 38 1.2 4 100 19 GNLF5104 2" 51 1.0 4 100 22 GNLF6404 2-1/2" 64 1.1 4 100 30 GNLF7604 3" 76 1.1 4 100 36 GNLF10304 4" 103 1.25 4 100 55 GNLF12735 5" 127 1.35 3.5 100 75 GNLF15303 6" 153 1.35 3 100 90 GNLF20303 8" 203 2.2 3 100 160 GNLF25525 10" 255 2.4 2.5 50 130 GNLF30502 12" 305 2.35 2 50 150 GNLF35802 14" 358 3.0 2 50 250 GNLF40802 16" 408 3.0 2 50 300 MEDIUM DUTY PVC LAY FLAT HOSE PARTNO. INCH I.D
(MM) THICKNESS
(MM) W.P.@23ºC
(BAR) LENGTH
(M/ROLL) WEIGHT
(KG/ROLL) GNLF2006 3/4" 20 1.35 6 100 11 GNLF2506 1" 25 1.3 6 100 16 GNLF3206 1-1/4" 32 1.2 6 100 19 GNLF3806 1-1/2" 38 1.2 6 100 22 GNLF5106 2" 51 1.35 6 100 30 GNLF6406 2-1/2" 64 1.55 6 100 43 GNLF7606 3" 76 1.5 6 100 50 GNLF10306 4" 103 1.9 6 100 80 GNLF12706 5" 127 2.0 6 100 108 GNLF15306 6" 153 2.4 6 100 160 GNLF20305 8" 203 2.6 5 100 220 HEAVY DUTY PVC LAY FLAT HOSE PARTNO. INCH I.D
(MM) THICKNESS
(MM) W.P.@23ºC
(BAR) LENGTH
(M/ROLL) WEIGHT
(KG/M) GNLF2010 3/4" 20 1.55 10 50 0.14 GNLF2510 1" 25 1.8 10 50 0.20 GNLF3210 1-1/4" 32 1.5 10 50 0.21 GNLF3810 1-1/2" 38 1.7 10 50 0.29 GNLF5110 2" 51 1.8 10 50 0.42 GNLF6410 2-1/2" 64 1.9 10 50 0.70 GNLF7610 3" 76 2.55 10 50 0.85 GNLF10310 4" 103 2.7 10 50 1.20 GNLF15308 6" 153 3.0 8 50 2.00 GNLF20306 8" 203 3.2 6 50 2.80
