St2000 Steel Cord Conveyor Belting
Hebei Jiuzhou Rubber Technology Co., Ltd.- Type：Conveyor Belt
- Feature：Wear-resistant, Heat-resistant, Tear-resistant, Flame-resistant, Cold-resistant
- Usage：Conveying Materials
- Performance：Strong Rubber Conveyor Belt
- Colour：Black
- Transport Package：Standard Packing
Base Info
- Model NO.：ST630,ST800,ST1000~~~ST7000,ST7500
- Specification：STANDARD: DIN, GB
- Trademark：JIUZHOU
- Origin：Hebei, China
- HS Code：40101200
Description
Specifications for Steel Cord Conveyor Belt under Standard DIN22131Type ST1000 ST1250 ST1600 ST2000 ST2500 ST3150 ST3500 ST4000 ST4500 ST5000 ST5400 Tensile strength (N/mm) 1000 1250 1600 2000 2500 3150 3500 4000 4500 5000 5400 Steel cord Max. Nominal diameter (mm) 4.1 4.9 5.6 5.6 7.2 8.1 8.6 8.9 9.7 10.9 11.3 Pitch of Cord (mm) 12±1.5 14±1.5 15±1.5 12±1.5 15±1.5 15±1.5 15±1.5 15±1.5 16±1.5 17±1.5 17±1.5 Thickness of Top Cover (mm) 4 4 4 4 5 5.5 6.5 7 7.5 8 9 Thickness of Bottom Cover (mm) 4 4 4 4 5 5.5 6.5 7 7.5 8 9 Width(mm) / tolerance Cord Number 500 ±5 39 34 650 ±7 51 44 800 ±8 64 55 50 64 1000 ±10 81 69 64 81 64 64 64 64 59 55 55 1200 ±10 97 84 77 97 77 77 77 77 71 66 66 1400 ±12 114 98 90 114 90 90 90 90 84 78 78 1600 ±12 131 112 104 131 104 104 104 104 96 90 90 1800 ±14 147 127 117 147 117 117 117 117 109 102 102 2000 ±14 164 141 130 164 130 130 130 130 121 113 113 2200 ±15 181 155 144 181 144 144 144 144 134 125 125 2400 ±15 197 169 157 197 157 157 157 157 146 137 137 2600 ±15 214 184 170 214 170 170 170 170 159 149 149 2800 ±15 231 198 170 214 170 170 170 170 159 149 149 3000 ±15 247 212 197 247 197 197 197 197 184 172 172 3200 ±15 264 227 210 264 210 210 210 210 196 184 184 500 ±5 39 34 650 ±7 51 44 800 ±8 75 75 64 55 50 64 1000 ±10 95 95 81 69 64 81 64 64 64 64 59 55 55 1200 ±10 113 113 97 84 77 97 77 77 77 77 71 66 66 1400 ±12 133 133 114 98 90 114 90 90 90 90 84 78 78 1600 ±12 151 151 131 112 104 131 104 104 104 104 96 90 90 1800 ±14 171 147 127 117 147 117 117 117 117 109 102 102 2000 ±14 164 141 130 164 130 130 130 130 121 113 113 2200 ±15 181 155 144 181 144 144 144 144 134 125 125 2400 ±15 197 169 157 197 157 157 157 157 146 137 137 2600 ±15 214 184 170 214 170 170 170 170 159 149 149 2800 ±15 231 198 170 214 170 170 170 170 159 149 149 3000 ±15 247 212 197 247 197 197 197 197 184 172 172 3200 ±15 264 227 210 264 210 210 210 210 196 184 184
