Hydraulic Hose DIN En 857 2sc Manufacturer
Qingdao Hyrotech Rubber & Plastic Products Co., Ltd.- Material：Natural Rubber
- Capability：Rubber Oil Hose
- Color：Black
- Size：Meet for SAE Standard
- Working Pressure：DIN Standard
- Lenght：100meters
Base Info
- Model NO.：DIN EN 857 2SC 1,4" to 1"
- Colour：Black or Other Cover
- Cover：Smooth or Wrapped
- Temperature：-40°c up to +100°c
- Applications：This Section Covers Hose for Use with Petroleum B
- Package：Plastic Woven Bag or PVC Film, Reels etc..
- Delivery Time：Within 30days for One FCL
- Quality Refer：Already Exported to More Than 40 Countries
- Transport Package：Plastic Woven Bag, PVC Film, Reel etc...
- Specification：1,4" to 1"
- Trademark：HYORTECH&HYROFLEX
- Origin：Shandong, China
- HS Code：40092100
- Production Capacity：5000000meters,Year
Description
SIZESAE I.D W.D O.D W. P P.P B.P min B.R W.T mm inch Dash Min Max Min Max Max Mpa Psi Mpa Psi Mpa Psi inch mm Kg/m 6.3 1/4" -04 6.1 6.9 10.6 11.7 14.2 40 5800 80 11600 160 23200 2.95 75 0.30 8 5/16" -05 7.7 8.5 12.1 13.3 16.0 35 5075 70 10150 140 20300 3.35 85 0.34 10 3/8" -06 9.3 10.1 14.4 15.6 18.3 33 4785 66 9570 132 19140 3.54 90 0.42 12.5 1/2" -08 12.3 13.5 17.5 19.1 21.5 27.5 3990 55 7975 110 15950 5.12 130 0.54 16 5/8" -10 15.5 16.7 20.5 22.3 24.7 25 3625 50 7250 100 14500 6.69 170 0.68 19 3/4" -12 18.6 19.8 24.6 26.4 28.6 21.5 3120 43 6235 86 12470 7.87 200 0.80 25 1" -16 25.0 26.4 32.5 34.3 36.6 16.5 2390 33 4785 66 9570 9.84 250 1.15
