Hydraulic Hose DIN En 857 1sc Manuacturer
Qingdao Hyrotech Rubber & Plastic Products Co., Ltd.- Material：Natural Rubber
- Capability：Rubber Oil Hose
- Color：Black
- Size：Meet for DIN Standard
- Working Pressure：DIN Standard
- Lenght：100meters
Base Info
- Model NO.：DIN EN 857 1SC 1,4" to 1"
- Colour：Black or Other Cover
- Cover：Smooth
- Temperature：-40°c up to +100°c
- Applications：This Section Covers Hose for Use with Petroleum B
- Package：Plastic Woven Bag or PVC Film, Reels etc..
- Delivery Time：Within 30days for One FCL
- Quality Refer：Already Exported to More Than 40 Countries
- Transport Package：Plastic Woven Bag, PVC Film, Reel etc...
- Specification：1,4" to 1"
- Trademark：HYORTECH&HYROFLEX
- Origin：Shandong, China
- HS Code：40092100
- Production Capacity：5000000meters,Year
Description
SIZESAE I.D W.D O.D W. P P.P B.P min B.R W.T mm inch Dash Min Max Min Max Max Mpa Psi Mpa Psi Mpa Psi inch mm Kg/m 6.3 1/4" -04 6.1 6.9 9.6 10.8 13.5 22.5 3260 45 6525 90 13050 2.95 75 0.20 8 5/16" -05 7.7 8.5 10.9 12.1 14.5 21.5 3120 43 6235 86 12470 3.35 85 0.15 10 3/8" -06 9.3 10.1 12.7 14.5 16.9 18 2610 36 5220 72 10440 3.54 90 0.19 12.5 1/2" -08 12.3 13.5 15.9 18.1 20.4 16 2320 32 4640 64 9280 5.12 130 0.23 16 5/8" -10 15.5 16.7 19.8 21.0 23.0 13 1885 26 3770 52 7540 5.91 150 0.29 19 3/4" -12 18.6 19.8 23.2 24.4 26.7 10.5 1520 21 3045 42 6090 7.09 180 0.34 25 1" -16 25.0 26.4 30.7 31.9 34.9 8.8 1280 17.6 2550 35.2 5100 9.06 230 0.4
