SAE 100r1at Steel Wire Braided Rubber Hydraulic Hose

Hengyu Group Hydraulic Fluid Technology Hebei Co., Ltd.
  • Material：Synthetic Rubber
  • Capability：Rubber Oil Hose
  • Color：Black
  • Temperature Range：-40°c , +100°c
  • Inner Tube：Oil Resistant Synthetic Rubber
  • Reinforcement：One Braid of High Tensile Steel Wire

Base Info

  • Model NO.：rubber hose
  • Cover：Environment Resistant Synthetic Rubber
  • Application：Low-Medium Pressure Lines
  • Standards：En853 1sn-SAE 100r1at-ISO 1436-1 1sn
  • Transport Package：Packed with PVC Films
  • Specification：Synthetic rubber
  • Trademark：HENGYU or OEM
  • Origin：Hebei, China
  • HS Code：4009210000
  • Production Capacity：30, 000 Meters Per Day

Description

Size (Inch)Inside DiameterReinforcementOutside DiameterProof PressureWorking PressureBurst PressureBend RadiusNom (mm)Min (mm)Max (mm)Min (mm)Max (mm)Nom (mm)Min (mm)Max (mm)(Bar)(Psi)(Bar)(Psi)(Bar)(Psi)(mm)3/16"4.84.65.491011.511.11350073002503650100014600851/4"6.46.2710.611.61312.71445065002253250900130001005/16"7.97.78.512.113.314.714.31643062002153100860124001153/8"9.59.310.114.515.71716.71836052001802600720104001301/2"12.712.313.517.519.120.119.8213204600160230064092001805/8"15.915.516.720.622.223.222.9252603800130190052076002003/4"1918.619.824.626.227.226.9292103000105150042060002401"25.42526.432.534.135.134.637176260088130035252003001-1/4"31.831.43339.341.742.842.24512618006390025236004201-1/2"38.137.739.345.64849.649.15210015005075020030005002"50.850.45258.761.762.562.566801200406001602400630

SAE 100r1at Steel Wire Braided Rubber Hydraulic Hose
SAE 100r1at Steel Wire Braided Rubber Hydraulic Hose
